Manual Syringe Gun Dispenser - 55cc - Precision Handheld Applicator for UV Cure Adhesives
Part Code: TS755SG-UV
Brand: Adhesive Dispensing Ltd

Precision Dispensing for Industrial Applications
The TS755SG-UV Manual Syringe Gun Dispenser is a high-quality, reusable handheld applicator engineered for the controlled dispensing of UV cure materials, and other assembly fluids. Supplied with 55cc (55ml) black coloursyringe barrels, this lightweight tool is ideal for low-volume production, rework, repair, and field-based applications.

Key Features & Benefits
- One-Handed Operation: Ergonomic design with a 7:1 mechanical leverage ratio for smooth, effortless trigger action.
- Precision Control: Delivers consistent 3mm (1/8") plunger movement per trigger pull - no drips, drool, or material waste.
- Quick Barrel Change: Secure bayonet twist-lock mechanism ensures stable barrel attachment under pressure.
- Durable Construction: Built from glass-filled nylon for strength and chemical resistance.
- Portable & Lightweight: Weighs just 0.1kg, making it easy to use for extended periods without fatigue.
- Easy Plunger Retraction: Push-button release for fast barrel replacement when empty.

What Is Included?
Each TS755SG-UV dispenser is supplied with a complete starter kit:
- (20) Syringe Barrel, 55cc Black Colour
- (20) Wiper Piston, 30/55cc White Colour
- (20) End Cap Seal, 30/55cc Orange Colour Snap-On
- (20) Tip Cap Seal, Orange Colour Luer Lock
- (10) Tapered Tip, 14 Gauge, Black Colour (1.6mm ID)
- (10) Tapered Tip, 16 Gauge, Black Colour (1.2mm ID)
- (10) Tapered Tip, 18 Gauge, Black Colour (0.84mm ID)
- (10) Tapered Tip, 20 Gauge, Black Colour (0.61mm ID)
- (10) Tapered Tip, 22 Gauge, Black Colour (0.41mm ID)
- (1) Setup Guide, Quick Start Instructions

For a complete kit containing more barrels, pistons and caps, order part TS755SG-KIT.

Technical Specifications
- Cartridge Capacity: 55cc (55ml)
- Standard Colour: Red
- Rod Length: 176.0mm
- Weight: 0.1kg
- Maximum Thrust: 1.5kN
- Mechanical Advantage: 7:1
- Handle & Body Material: Glass-Filled Nylon
- Viscosity Range: Low to Medium
- Warranty: 1 Year Against Fault
- Compliance: REACH Approved
- Commodity Code: 39269097
- Brand: Adhesive Dispensing Ltd

Material Compatibility
Do Not Use with:
- Cyanoacrylate adhesives (super glues)
- Rapid-cure two-part epoxies
- Aggressive solvents or chemicals

Compatible With:
- UV Cure adhesives
- Solder pastes & fluxes
- RTV silicones & sealants
- PVA glues & SMT adhesives
- Single-part epoxies & pre-mixed frozen epoxies
- Greases, gels, primers, inks, and other assembly fluids

Versatile Dispensing Solutions
Adhesive Dispensing Ltd provides full-service equipment support for fluid applications - from watery activators and primers to highly viscous gels, adhesives, and sealants. Our systems ensure precise dispensing, minimal waste, and clean transfer, backed by reliable technical support.
