Mixer Nozzle Bayonet 6mm ID x 21 Elements MAH 06-21L

Mixer Nozzle Bayonet 6.3mm ID x 21 Elements MAH06-21L Adhesive Dispensing Sulzer Mixpac
Mixer Nozzle Bayonet 6.3mm ID x 21 Elements MAH06-21L Adhesive Dispensing Sulzer Mixpac Mixer Nozzle Bayonet 6.3mm ID x 21 Elements MAH06-21L Adhesive Dispensing Sulzer Mixpac Mixer Nozzle Bayonet 6.3mm ID x 21 Elements MAH06-21L Adhesive Dispensing Sulzer Mixpac
Mixer Nozzle Bayonet 6mm ID x 21 Elements MAH 06-21L
Product Code: MAH06-21L-10

ID: 6.3mm. Elements: 21. Length: 153mm. Volume: 3.6ml. For 50ml 1:1/2:1 Cartridges.

Bayonet inlet, helical static mixer for 50ml, 75ml and 100ml cartridges. Luer outlet that can be used with all our precision dispensing tips. These mixer nozzles are suitable 1:1 and 2:1 ratio two-component materials. They have white elements and are constructed of high grade polypropylene. High quality mixer nozzles for use with twin cartridges. All items are industrial grade safe and silicone free. With a 6.3mm inner diameter x 21 mixing elements.
If a higher level of control for smaller deposits is required, use any of our range of dispensing tips with this nozzle. The luer tip will push over the tapered end of the nozzle end to provide a smaller outlet for finer controlled deposits. Dispensing tips are available in many different styles including smooth flow tapered, precision metal and bent.
Part ID: MAH06-21L
Material: Polypropylene
Colour: Natural Outer, White Elements
Inner Diameter: 6.3mm
Outer Diameter: 9mm
Length: 151mm
Nozzle Outlet: Luer Lock
Elements: 21
Retained Volume: 3.6ml
Details: Industrial Grade, Silicone Free
Commodity Code: 39269097
Brand: Sulzer Mixpac Medmix
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
Pack Size Options
Price: £6.00   Exc VAT
  • Product Brand:Sulzer Mixpac Medmix
  • MPN: MAH06-21L-10Lead Time: Ships In 24 Hours - Stock ItemPack Size: 50
