Mix Nozzle 3.2mm ID x 12 EL 114250 MKH03-12S

Name: Mix Nozzle 3.2mm ID x 12 EL 114250 MKH03-12S - F. Pack of 1000
Brand: Sulzer Mixpac Medmix
Price: 360.00 GBP
Availability: InStock

Static mix nozzle K System Adhesive Dispensing MKH03-12S 114250 Sulzer Mixpac

Product Code: MKH03-12S-10

Mix nozzle, 3.2mm ID, 12 Element, Length: 61.0mm, Volume: 0.39ml, 1:1/2:1 Ratio.

Small Shot Mixer Nozzles for Two-Component Adhesives

The K system dual syringes are ideal for one shot or small volume dispensing of fully mixed materials.

This part code is for the static mixer nozzle used with the 1:1, 2:1 ratio sets only. Light grey cap. Natural body with white mix elements.

12 mix elements - 3.2mm ID. Overall nozzle length 61mm. Volume of retained material is 0.39ml. Tapered outlet for high precision dispensing control. Supplied in sealed packs of 100 nozzles.

Part ID: 114250 (MKH03-12S)

Material: Polypropylene
Colour: Natural Body, Grey Cap, White Mix Elements
Length: 61.0mm
ID: 3.2mm
Elements: 12
Volume: 0.39ml
Ratio: 1:1/ 2:1
Details: Industrial grade, Silicone Free
Commodity Code: 39269097
Brand: Sulzer Mixpac Medmix

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
