Mix Nozzle 2.5mm ID x 12 EL 114261 MKHX02-12D

Name: Mix Nozzle 2.5mm ID x 12 EL 114261 MKHX02-12D - F. Pack of 1000
Brand: Sulzer Mixpac Medmix
Price: 468.00 GBP
Availability: InStock

Static mix nozzle K System Adhesive Dispensing 114261 MKHX02-12D Sulzer Mixpac

Product Code: 114261 MKHX02-12D-10

Mix nozzle, 2.5mm ID, 12 Element, Length: 46.2mm, Volume: 0.23ml, 10:1 ratio. Open outlet

Small Shot Mixer Nozzles for Two-Component Adhesives

The K system dual syringes are ideal for one shot or small volume dispensing of fully mixed materials.

This part code is for the static mixer nozzle used with the 10:1 ratio sets only. Light grey cap. Natural body with orange mix elements.

12 mix elements - 2.5mm ID. Overall nozzle length 46.2mm. Volume of retained material is 0.23ml. This nozzle features a straight outlet for higher material flow rates. Supplied in sealed packs with labels and batch codes.

Part ID: 114261 (MKHX02-12D)
Material: Polypropylene
Colour: Natural Outer/ Orange Element
Length: 46.2mm
Inner Diameter: 2.5mm
Elements: 12
Volume: 0.23ml
Ratio: 10 to 1 Only
Details: Industrial grade, Silicone Free
Commodity Code: 39269097
Brand: Sulzer Mixpac Medmix
