Mix Nozzle 2.5mm ID x 12 EL 114253 MKH02-12D

Name: Mix Nozzle 2.5mm ID x 12 EL 114253 MKH02-12D - F. Pack of 1000
Brand: Sulzer Mixpac Medmix
Price: 384.00 GBP
Availability: InStock

Static mix nozzle K System from Adhesive Dispensing MKH02-12D Sulzer Mixpac 114253

Product Code: 114253 MKH02-12D-10

Mix nozzle, 2.5mm ID, 12 Element, Length: 46.2mm, Volume: 0.23ml, 1:1, 2:1 ratio. Open outlet

Small Shot Mixer Nozzles for Two-Component Adhesives

The K system dual syringes are ideal for one shot or small volume dispensing of fully mixed materials. This version has an open end for faster material flow rates.

This part code is for the static mixer nozzle used with the 1:1 & 2:1 ratio sets only. Light grey collar. Natural body with white mix elements.

12 mix elements - 2.5mm ID. Overall nozzle length 46.2mm. Volume of retained material is 0.23ml. Straight outlet design for higher material flow. Supplied in sealed packs with label and batch codes.

Part ID: 114253 (MKH 02-12D)
Material: Polypropylene
Colour: Natural Body, White Element, Grey Cap
Element Type: Helix
Length: 46.2mm
Inner Diameter: 2.5mm
Number of Elements: 12
Material Volume: 0.23ml
Ratio: 1:1, 2:1
Maximum Pressure: 100 PSI
Details: Industrial Grade, Silicone Free
Commodity Code: 39269097
Brand: Sulzer Mixpac Medmix

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Price: £6.50 Exc VAT

Product Brand:Sulzer Mixpac Medmix
MPN: 114253 MKH02-12D-10Lead Time: Ships 24 Hours - Stock ItemPack Size: 10
