Mix Nozzle 2.5mm ID x 12 EL 114249 MKH02-12S

Static Mix Nozzle K System Adhesive Dispensing Ltd MKH02-12S 114249 Sulzer Mixpac Medmix

Product Code: MKH02-12S-10

Mix nozzle, 2.5mm ID, 12 Element, Length: 49.7mm, Volume: 0.23ml, 1:1/2:1 ratio. Tapered Outlet

Small Shot Mixer Nozzles for Two-Component Adhesives

The K system dual syringes are ideal for one shot or small volume dispensing of fully mixed materials. This part code is for the static mixer nozzle used with the 1:1 ratio sets only. Light grey collar. Natural body with white mix elements.

This mixers has 12 mix elements and a 2.5mm ID. The overall nozzle length 49.7mm. Volume of retained material is 0.23ml. Tapered outlet design providing high levels of deposit control. Supplied in sealed packs with labels and batch codes for traceability.

Part ID: 114249 (MKH02-12S)
Material: Polypropylene
Colour: Natural, Grey Cap, White Element
Length: 49.7mm
ID: 2.5mm
Elements: 12
Volume: 0.23ml
Ratio: 1:1, 2:1
Details: Industrial Grade, Silicone Free
Commodity Code: 39269097
Brand: Medmix Sulzer Mixpac

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
