Premium grade polyethylene luer lock taper tips for use with all adhesives, pastes, gels, epoxies, silicones, grease and UV cure. The tip length is 1.25" - 31.75mm. The tapered design allows smooth flow of all viscosity materials, improving flow rates and reducing back pressure. Available in 19 colour coded gauge sizes with inner diameters of 3.5mm to 0.10mm. Optional versions of ESD safe material and UV black colour. Industrial grade safe to 100 PSI. Silicone-free parts. Supplied in boxes of 50, 500 or 1000.
Premium grade micro metal tapered dispensing tips reduce pressure and increase flow rates. Outlet hole inner diameter sizes of 0.06mm to 1.4mm. High quality constructed tips used on XYZ systems for SMT adhesives and materials where high precision is required. Industrial grade safe for use to 100 psi. Luer locking hub provides secure attachment to valves, syringes, fittings, etc.
Premium blunt end precision tips with tube lengths of 1/4”, 1/2, 1”, 1.5”, 2”, 3", 4", 5". Gauge sizes of 10 to 34. Polypropylene double helix leur lock Colour coded hub to stainless steel blunt tube. Suitable for all liquid, paste and adhesive types. High quality products that are silicone and chloride free. Safe for use to 100 psi pressure. In boxes of 50 or bulk packs of 500 or 1000.
Precision crimped tube tips. Outlet hole diameter sizes of 1.55 mm ID to 0.15mm. Suitable for use with most adhesives, solvents, primers, activators, UV cure adhesives and more. 0.25", 0.50" or 1.0 long. Polypro colour coded luer lock hub material crimped to stainless steel tube. Supplied in boxes of 50 or bulk packs of 500 or 1000.
Budget range general purpose dispensing tips. Outlet hole diameter sizes of 1.60 mm ID to 0.10mm. Suitable for use with most adhesives, silicones, primers, activators, UV cure and more. 0.25", 0.50", 1.0". 1.5" long tube lengths. Polypro colour coded luer lock hub bonded to a stainless steel tube. Supplied in boxes of 50 or bulk packs of 500 or 1000.
Low cost range of blunt end dispensing tips. Outlet hole diameter sizes of 1.70 mm ID to 0.16mm ID. Suitable for use with most adhesives, silicones, primers, activators, UV cure and more. 0.25", 0.50", 1.0" and 1.5" long precision tube lengths. Polypro colour coded luer lock hub epoxy bonded to a stainless steel tube. Supplied in sealed bulk packs of 1000 tips.
Precision aluminium needle dispense tips. Outlet hole diameter sizes of 1.55mm to 0.71mm. Suitable for use with aggressive solvent based liquids or chemicals where standard tips would perish. In tubing lengths of 0.5", 1.0", 1.5" or 2.0". Aluminium luer lock hub welded to stainless steel precision tube. Supplied in boxes of 50 or bulk packs of 500 or 1000.
High quality hand assembled all-metal dispense tips. Outlet hole diameter sizes of 3.28mm to 0.15mm. Designed for use with most adhesives, inks, primers, glues, grease, gels and more. Any length - we make to order. Nickel plated brass luer lock hub to stainless steel tube. Precision tips ideal for automated applications and robots. In sealed packs of 10 or 12 tips.
Precision bend 30, 45, 60 or 90 degree angled bent tube tips. Outlet hole diameter sizes of 1.60 mm ID to 0.10mm. Suitable for use with most adhesives, silicones, primers, activators, UV cure adhesives and more. 0.50", 1.0" or 1.5" long. Polypro colour coded double helix luer lock hub to stainless steel tube. Supplied in boxes of 50 or bulk packs of 500 or 1000.
Flexible polypro tube tips. Outlet hole diameter sizes of 1.40mm to 0.25mm. Ideal for use with adhesives, inks, primers, glues, Cyanoacrylates, paints and many more. 0.50", 1.0", 1.5" and long. Polypro hub material to polypro flexible tubes. Colour coded luer lock hubs. Soft tubing is also ideal for sensitive substrates. Supplied in boxes of 50 or bulk packs of 500 or 1000.
Flexible tube dispense tips. Outlet hole diameter sizes of 1.55mm to 0.35mm. Ideal for use with adhesives, inks, primers, glues, Cyanoacrylates, paints and many more. In tube lengths of 1.5" only. Polypro hub material to polypro flexible tubes. White hubs to colour coded shafts. Soft tubing is also ideal for sensitive substrates. Supplied in sealed packs direct from stock.
PTFE tube tips for dispensing Cyanoacrylate adhesives. Outlet hole diameter sizes of 0.51mm to 0.20mm. Recommended for use with adhesives, especially CA glues where the PTFE tubing resists clogging. Range of tube lengths. Polypropylene double helix luer lock hub material to flexible translucent tube. Supplied in sealed packs direct from stock.
PTFE-lined tips for dispensing Cyanoacrylate adhesives. PTFE tube ID of 1.4mm, 0.51mm, 0.3mm and 0.2mm. Recommended for use with adhesives, especially Cyanoacrylate glues as the PTFE tube resists clogging. 1/4", 1/2", 1" or 1.5" tube lengths. Straight tube or 45 degree bend version. Polypro luer lock hub to stainless steel tube with PTFE crimp insert.
Chamfered tube tips for low viscosity liquids. The taper at the end outlet of the tip reduces the surface area a solvent or other low-viscosity fluid can grip, providing better dispensing control. Chamfered tips are ideal for dispensing between delicate surfaces or making exact, repeatable micro-deposits. Tube lengths of 0.25” and 0.5”.
All ESD safe tips are premium grade and due to the ESD graphite additive, all hub colours are black which also makes them suitable for use with UV cure adhesives. These tips remove electro-static discharge. Available as smooth flow tapered, blunt-end straight and precision bent. Tips are silicone-free materials and industrial grade safe to 100 psi air pressure.
Precision brush tips for coating and spreading. Outlet hole diameter sizes of 1.60mm to 0.25mm. For use with glues, grease, paints, inks, gels, primers, sealants and more. In lengths of 1.5" only. Brush widths of 2mm to 14mm wide. Hard or soft bristle. Double helix luer lock hubs. High quality tips for spreading, coating and bonding applications. In packs of 1 or 10.
Assortment of different tip kits excellent for evaluation and testing purposes. Available in presentation boxes or in smaller kits. Ideal for use with glues, grease, paints, inks, gels, primers, sealants and more. Select the type of tip kit to suit the applications or testing. We can also make up kits to suit so please contact us with details. All kits ship direct from stock.
Luer Lock Tips
Offering the widest range of dispensing tips for use with syringe barrels, bottles, metering valves and XYZ robots. All tips are industrial grade safe for use up to 100 psi fluid pressures and are certified silicone-free. Featuring luer lock safe and secure attachment for leak free dispensing.
Our extensive range of dispensing tips are suitable for use on luer lock and luer slip syringe barrels, fittings, dosing valves and luer bottles. All tips feature a female luer lock hub for safe connection at air pressures up to 100 psi and are certified industrial grade safe and silicone free. Tips can be used with most fluids, adhesives, pastes or chemicals.
Tips are colour coded by size, ranging from 14 gauge (1.6mm ID) to 34 gauge (0.08mm ID). Special use tips include Teflon Lined for Cyanoacrylates, flexible Polypro for potting and Brush for spreading, marking and coating. Tapered tips are ideal for thick pastes & gels, Bent tips for getting into edges or seams, all-metal tips for use on robots and Aluminium for solvent based glues.
All dispensing tips twist onto luer lock syringe barrels or fittings or push onto luer slip syringe barrels for a secure attachment. We stock almost all products for a delivery within 48 hours of order or sooner. Products are high quality for precision dispensing and are not medical type needles.
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
