The F4200N.2 bench top dispensing robot is a cost effective solution combining high level programming technology with precision placement engineering. The 4000 series is a compact, heavy duty design, which is easily programmed using simple step-by-step instructions. A robust cast construction provides additional stability when working to fine tolerances. Each robot is capable of interfacing with other Adhesive Dispensing equipment.

Systems will dispense virtually any assembly fluid and adhesive or liquid paste, from thin, watery liquids and solvents to thick gels, silicones and brazing pastes. All are applied quickly, accurately to reduce waste, mess and hand fatigue.

Programming is simple with easy to follow english language instructions. Commands are followed and responses entered by a teach pendant. An LCD display prompts the user for a data input and once confirmed, automatically displays the next instruction. By this method a program can be created quickly and simply. All machines include 16 I/O signal interface for connection to tools and controllers. Includes the DC50 MAX digital dispenser as part of the package.
