6oz Automatic Syringe Filling Station 9150-6SF

Name: 6oz Automatic Syringe Filling Station 9150-6SF
Brand: ADL
SKU: 9150-6SF
Price: 521.06 GBP
Availability: InStock

Product Code: 9150-6SF

Size: 6oz/ 177ml. Max Pressure: 100 PSI. Retainer: Metal. Type: Dispenser Activation.

The model 9150-6SF loads a barrel directly from a 6oz (177cc/ml) cartridge. This barrel loader includes a timed dispenser station allowing the operator to set the fill size, press the pedal for repeat filling amount to each syringe barrel. This takes away the need for the operator to judge the deposit size. The timer adjustment can be set to fill any syringe barrel size. High pressure dispenser up to 100 PSI.

The dispenser is controlled via the supplied foot switch. The dispenser is 110/220V power so can be used anywhere in the world. This kit is supplied ready to use including all fittings and sample syringe barrels. A fast and easy barrel loader to bottom fill syringes without excessive air entrapment. Use standard 6oz industrial cartridges. The barrel attachment assembly is threaded to accept all luer lock barrels. This version of loader has a metal body retainer and cap.

Part ID: 9150-6SF
Materials: Stainless Steel/ Nylon
Capacity: 6oz (177cc/177ml)
Weight: 1kg
Max Pressure: 100 PSI (7 Bar)
Warranty: 12 Months

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Price: £434.22 Exc VAT

Product Brand:ADL
MPN: 9150-6SFMax Pressure: 100 PSILead Time: 5-7 Days
