CG400-2 Pneumatic Dispensing Gun for Two-Component Cartridges
The CG400-2 air-powered cartridge gun is a high-performance, industrial-grade applicator designed for dispensing epoxy-based, two-component adhesives and sealants. Engineered for precision and efficiency, this pneumatic dispensing gun is rod-driven, allowing for adjustable air pressure control to modify forward and reverse rod speeds. This ensures optimal resin flow rate, making it adaptable to various viscosities and application requirements.
Key Features & Benefits:
- Versatile Dual-Component Dispensing – Designed for side-by-side cartridges, suitable for bead and potting applications.
- Industry-Standard Mixing Ratios – Supports 1:1, 2:1, 4:1, and 10:1 ratios, ensuring compatibility with multiple formulations.
- Adjustable Air Pressure System – Fine-tune dispensing speed and viscosity control for maximum precision.
- Heavy-Duty & Durable – Constructed from aluminium, nylon, polypropylene, steel, and zinc for long-lasting performance in aerospace, electronics, automotive, and construction industries.
- Quick Cartridge Adaptation – Includes fast-change kit for seamless ratio adjustments, completed within seconds.
- Lightweight & Ergonomic – Weighs just 3.17kg, ensuring comfortable handling without compromising performance.
Technical Specifications:
- Part Code: CG400-2
- Drive Type: Pneumatic Cylinder to Rods
- Air Supply: 6.80 Bar (100 PSI) Maximum
- Power Output: 2.00 kN
- Dimensions: Length – 609mm
- Weight: 3.17kg
- Compatible Cartridge Sizes: 200ml, 210ml, 215ml, 225ml, 250ml, 395ml, 400ml, 415ml, 490ml
- Mix Ratios Supported: 1:1, 2:1, 4:1, 10:1
- Stock Availability: Yes
- Warranty: 1 Year
- Compliance: CE Approved
- Commodity Code: 90289090
- Manufactured In: Taiwan
Click Here For Data Sheet
Compatible with the cartridge types on image 2
Optimised for a Wide Range of Adhesive Applications
Adhesive Dispensing Ltd offers an extensive range of high-performance dispensing solutions, catering to various assembly fluids—from watery liquids, solvents, and primers to high-viscosity pastes, sealants, silicones, gels, and epoxies.
