310ml Cartridge Retainer System 100A-R10

Name: 310ml Cartridge Retainer System 100A-R10
Brand: Adhesive Dispensing Ltd
SKU: 100A-R10
Price: 234.00 GBP
Availability: InStock

10oz Cartridge Retainer Cap & Hose 100A-R10 Adhesive Dispensing Ltd

Product Code: 100A-R10

10oz (310ml). 8.99" (228.34mm) Long. OD: 1.85" (46.99mm). Threaded Attachment.

10oz (310ml) size cartridge retainer body with air cap for use with a euro 310ml size sealant or silicone tube cartridge. Supplied with threaded metal retainer and built-in compact adjustable regulator to control air flow. Uses a 5mm push fit air connection and supplied with a 6ft length of 5mm air tubing and a 1/4 Inch BSP connector.

Accepts 10oz cartridges as well as all 310ml size pre-filled silicone/ sealant tubes. The metal retainer body is unscrewed and the cartridge placed inside. Allows materials to be fed under pressure up to 100 psi. Can be used as a pneumatic cartridge feed reservoir to Spool Valves or connected directly to an air-powered timed shot dispenser. Product is covered by a 1 Year warranty.

Part ID: 100A-R10
Materials: Aluminium/ Steel/ Nylon
Colour: Black
Max Pressure: 100 PSI
Diameter: 1.90 Inch
Length: 10.85 Inch
Warranty: 1 Year
Commodity Code: 84679200
Brand: Adhesive Dispensing Ltd
Origin: GB

Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids - from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.

Price: £195.00 Exc VAT

Product Brand:Adhesive Dispensing Ltd
MPN: 100A-R10Lead Time: Ships Within 24 HoursMax Pressure: 100 PSI
