TS1251 Pressure Pot – 75 PSI Industrial Fluid Reservoir for Solvents, Epoxies, Cyanoacrylates & UV Adhesives
The TS1251 pressure pot is a high-quality, industrial-grade fluid reservoir designed for safe and consistent dispensing of solvents, epoxies, cyanoacrylates, UV adhesives and other assembly fluids. Rated to 75 PSI, this pressure pot provides a stable, airtight environment that ensures smooth material flow without leakage, air entrapment or pressure fluctuations.
The system accommodates 6mm OD feed tubing using stainless steel compression fittings, providing a continuous fluid path from the reservoir inside the pot to the metering valve. A 1/8" male luer lock fitting is also supplied to accept standard fluid lines. The TS1251 is ideal for use with bottles of cyanoacrylate and anaerobic adhesives and supports viscosities up to 25,000 CPS. It accepts adhesive bottles of 250g, 500g and 1lb.
Key Features
Airtight, Leak-Free Design
- Prevents air entrapment and fluid contamination
- Ensures stable pressure for consistent dispensing
- Suitable for moisture-sensitive adhesives
Continuous Fluid Path
- 6mm OD stainless steel compression fittings
- Direct feed from reservoir to metering valve
- Includes 1/8" male luer lock for standard fluid lines
Industrial Construction
- Black and silver anodised aluminium body
- Durable 6-6 nylon top and base
- Designed for long-term industrial use
Technical Specifications
| Part ID |
TS1251 |
| Max Pressure |
75 PSI |
| Max Fluid Viscosity |
Up to 25,000 CPS |
| Air Inlet |
6mm Push Fit |
| Material Outlet |
6mm OD Metal Tube Connector |
| Materials |
Aluminium body, 6-6 nylon top and base |
| Outer Size |
6.25" W × 12.50" H (158.75mm × 317.5mm) |
| Inner Chamber |
3.75" W × 9.63" H (95.25mm × 244.6mm) |
| Weight |
2.06kg |
| Colour |
Silver / Black |
| Warranty |
1 Year |
| Commodity Code |
84798997 |
| Included Components |
TSD800-6EL regulator and pressure gauge,
1/8" elbow to 6mm push-fit,
6mm natural PE tubing (2m),
6mm black PE tubing (2m) |
Ideal Applications
- Solvent dispensing
- Epoxy and resin feed systems
- Cyanoacrylate bottle pressurisation
- UV adhesive dispensing
- Automated metering valve systems
- Industrial assembly and electronics manufacturing
Adhesive Dispensing Ltd provide a wide range of equipment options for dispensing almost all assembly fluids – from watery liquids, solvents, primers and activators through to thick pastes, sealants, silicones, gels and epoxies.
